CCP 5-15/20

Rotary Evaporators


DESCRIPTION :

•Temperature range: -15- room temperature

•Employs PID temperature control with built-in PT1000 temperature sensor that provides high accuracy of temperature control

•Employs PID temperature control with built-in PT1000 temperature sensor that provides high accuracy of temperature control

•The entire unit is capable of protection against short circuit, over-current, overload and delayed start

•Integrated design of drain outlet and water outlet that allows easy drainage

•German-made pump that is environment-friendly, low-noise and durable

The compressor employs state-of-the-art R290 environment-friendly refrigerant to protect environment and human health.

Specifications CCP5-15
Temperature range -15- room temperature
Temperature adjustment accuracy 0.1℃
Temperature control accuracy ±0.1℃（-20℃~0℃ typical value）
±0.5℃（0℃~20℃ typical value）
Reservoir capacity 5L
Range of temperature adjustment -30℃～30℃
Temperature display LED
Type of temperature sensor PT1000
Compressor refrigerant R290
Circulating pump throughput 12L/MIN
Circulating pump head 6m
In-out cycle interface 12mm pagoda-type interface
RS232 interface Yes
Machine power 350W
Maximum overall dimensions 370*460*700（mm）
Power supply 220V 50Hz/60Hz
Operating environment 10℃～40℃ ≤80% RH
