APERA TN 500
APERA INSTRUMENT
DESCRIPTION :
Apera TN500 uses a tungsten filament lamp as the light source and 90° scattering method, which is compliant with the U.S EPA 180.1 method for the determination of turbidity in drinking, ground, surface, and saline waters, domestic and industrial wastes. The instrument is designed for water quality professionals, offering long-term reliability in high-accuracy turbidity measurement with an intuitive operation system, simple calibration, and GLP data management.
The meter is equipped with a large TFT color screen with plain language and graphic navigation, supporting English, Spanish, and Chinese. Intelligent functions such as automatic calibration, real-time clock display, calibration date check, auto. power off, and low battery reminder are built-in to ensure ease of use.
200 sets of data storage with USB data output to PC (Windows-based only)
The kit comes with AMCO® high-molecular polymer turbidity standard solutions (0, 20, 100, 400, 800 NTU), which are EPA approved primary standards that are safe, non-toxic and disposable, and have a guaranteed one-year shelf life. It is NIST traceable to particle size/distribution and optical density, and its inherent stability means it does not settle from suspension. Store the standards at room temperature.
Specification
Measurement Method: 90° scattering measurement, U.S EPA180.1 compliant
Light Source: Tungsten filament lamp
Measuring Range: 0 to 1000 NTU (FNU), automatic range switch
0.01 to 19.99 NTU(FNU)
20.0 to 99.9 NTU(FNU)
100 to 1000 NTU(FNU)
Accuracy: ≤ ±2% of reading+ stray light
Repeatability: ≤ ± 1% of reading or 0.02 NTU(FNU) (the greater of the two)
Resolution: 0.01/0.1/1 NTU (FNU)
Stray Light: ≤0.02 NTU (FNU)
Calibration Standard: AMCO Polymer or Formazin Solution：0, 20, 100, 400 and 800NTU (FNU)
Detector: Silicon photovoltaic
Measuring Mode: Normal measurement and TruRead measurement
Data Storage: 200 groups
Data Output: USB to PC
Calibration Record: Calibration date and time
Display: TFT color screen
Sample Vial: Φ25×60 mm，high borosilicate glass with lid
Sample Vial Volume: 18 ml
Power supply: 3.7V Rechargeable lithium battery
Working Condition: Temperature: 0 to 50°C（32°F to 122°F）；Relative humidity：
0 to 90% at 30°C, 0 to 80%at 40°C, 0 to 70% at 50°C, no condensation
Instrument sealing grade: IP67
Certificates: ISO9001:2015 and CE
Dimension and Weight Meter: (90×203×80) mm/385g
Test Kit: (310×295×110) mm/1.5kg
DESCRIPTION :
Apera TN500 uses a tungsten filament lamp as the light source and 90° scattering method, which is compliant with the U.S EPA 180.1 method for the determination of turbidity in drinking, ground, surface, and saline waters, domestic and industrial wastes. The instrument is designed for water quality professionals, offering long-term reliability in high-accuracy turbidity measurement with an intuitive operation system, simple calibration, and GLP data management.
The meter is equipped with a large TFT color screen with plain language and graphic navigation, supporting English, Spanish, and Chinese. Intelligent functions such as automatic calibration, real-time clock display, calibration date check, auto. power off, and low battery reminder are built-in to ensure ease of use.
200 sets of data storage with USB data output to PC (Windows-based only)
The kit comes with AMCO® high-molecular polymer turbidity standard solutions (0, 20, 100, 400, 800 NTU), which are EPA approved primary standards that are safe, non-toxic and disposable, and have a guaranteed one-year shelf life. It is NIST traceable to particle size/distribution and optical density, and its inherent stability means it does not settle from suspension. Store the standards at room temperature.
Specification
Measurement Method: 90° scattering measurement, U.S EPA180.1 compliant
Light Source: Tungsten filament lamp
Measuring Range: 0 to 1000 NTU (FNU), automatic range switch
0.01 to 19.99 NTU(FNU)
20.0 to 99.9 NTU(FNU)
100 to 1000 NTU(FNU)
Accuracy: ≤ ±2% of reading+ stray light
Repeatability: ≤ ± 1% of reading or 0.02 NTU(FNU) (the greater of the two)
Resolution: 0.01/0.1/1 NTU (FNU)
Stray Light: ≤0.02 NTU (FNU)
Calibration Standard: AMCO Polymer or Formazin Solution：0, 20, 100, 400 and 800NTU (FNU)
Detector: Silicon photovoltaic
Measuring Mode: Normal measurement and TruRead measurement
Data Storage: 200 groups
Data Output: USB to PC
Calibration Record: Calibration date and time
Display: TFT color screen
Sample Vial: Φ25×60 mm，high borosilicate glass with lid
Sample Vial Volume: 18 ml
Power supply: 3.7V Rechargeable lithium battery
Working Condition: Temperature: 0 to 50°C（32°F to 122°F）；Relative humidity：
0 to 90% at 30°C, 0 to 80%at 40°C, 0 to 70% at 50°C, no condensation
Instrument sealing grade: IP67
Certificates: ISO9001:2015 and CE
Dimension and Weight Meter: (90×203×80) mm/385g
Test Kit: (310×295×110) mm/1.5kg
